# Linear Least Squares

Least squares models are ubiquitous in science and engineering. In fact, the term *least squares* can have various meanings in different contexts:

**Algebraically**, it is a procedure to find an approximate solution of an overdetermined linear system – instead of trying to solve the equations exactly, we minimize the sum of the squares of the residuals.**In statistics**, the least squares method has important interpretations. For example, under certain assumptions about the data, it can be shown that the estimate coincides with the*maximum-likelihood*estimate of the parameters of a linear statistical model. Least square estimates are also important even when they do not coincide exactly with a*maximum-likelihood*estimate.**Computationally**, linear least squares problems are usually solved by means of certain orthogonal matrix factorizations such as QR and SVD.

## Computing Least Square Solutions

Given a matrix \( A \in \mathbf{R}^{n \times m} \) and a right-hand side vector \( b \in \mathbf{R}^{n} \) with \( m < n \), we consider the minimization problem

$$ \tilde{x} = \mbox{arg min}_{x} \| Ax - b \|_2 $$

### Solving the Normal Equations

As most linear algebra textbooks show, the most straightforward method to compute a least squares solution is to solve the normal equations

$$ A^t A x = A^t b $$

This procedure can be implemented in Julia as:

```
x = A^t A \ A^t b
```

However, this is not the most convenient method from a numerical viewpoint, as the matrix \( A^t A \) has a condition number of approximately \( cond(A)^2 \), and can therefore lead to amplification of errors. The QR method provides a much better alternative.

### Least squares via QR Decomposition

Another way of solving the Least Squares problem is by means of the QR decomposition (see Wiki), which decomposes a given matrix into the product of an orthogonal matrix Q and an upper-triangular matrix R .

Replacing \( A = QR \), the normal equations now read:

$$ (QR)^t QR x = (QR)^t b $$

Now, given the identity \( Q^tQ = I \), this expression can be simplified to

$$ R x = Q^t b, $$

For well-behaved problems, at this point we have a linear system with a unique solution. As the matrix \( R \) is upper-triangular, we can solve for \( x \) by back-substitution.

In Julia, the least-squares solution by the QR method is built-in the backslash operator, so if we are interested in obtaining the solution of an overdetermined linear system for a given right-hand side, we simply need to do:

```
x = A\b
```

There are cases where we want to obtain and store the matrices Q and R from the factorization. An example is when, for performance, we want to pre-compute these matrices and reuse them for multiple right-hand sides. In such case, we do

```
qrA = qr(A); # QR decomposition
x = qrA\b;
```

## Example: Fitting a 2D Ellipse from a Set of Points

Let’s focus in an interesting curve-fitting problem, where we are given \( n \) pairs of points \( x_i, y_i \) and we want to find the ellipse which provides the best fit.

There are indeed many ways of solving this curve-fitting problem (see for example this paper.

The most basic method starts with noting that the points of a general conic satisfy the following implicit equation:

$$ a x^2 + bxy + c y^2 + dx + ey + f = 0 $$

The above equation can be normalized in various ways. For example, we can resort to the alternative formulation:

$$ a x^2 + bxy + c y^2 + dx + ey = 1 $$

This leads to the problem of finding the best-fitting coefficients \( a,b,c,d,e \) as a least-squares problem for the following \( n \) equations with 5 unknowns:

$$ a x_i^2 + b x_i y_i + c y_i^2 + dx_i + ey_i = 1 \qquad 1 \le i \le n $$

Let’s generate some random test data

```
θ = π/7; a = 2; b = 1.5; x_0 = 3; y_0 = -1;
fx(t) = a*cos(θ)*cos(t) - b*sin(θ)*sin(t) + x_0
fy(t) = a*sin(θ)*sin(t) + b*cos(θ)*cos(t) + y_0
N = 200;
ts = LinRange(0,2π,N);
x = fx.(ts) + randn(N)*0.1;
y = fy.(ts) + randn(N)*0.1;
```

We now construct the design matrix

```
A = [x.^2 y.^2 x.*y x y ]
```

and compute the least-squares solution with the backslash operator:

```
p = A\ones(N)
```

Thats it! We have obtained the parameters of the implicit equation.

### Plotting the Implicit Curve as a Countour Line

However, if we want to plot the resulting curve, we must solve an additional problem. Given \( a,b,c,d,e \), how can we find points satisfying:

$$ a x^2 + bxy + c y^2 + dx + ey = 1 $$

and plot them?

Fortunately, this can be easily accomplished by resorting to contour plots. In order to do this, we construct a grid and we evaluate the (bivariate) polynomial expression field. Then, we seek the contour level equal to one. Under the hood, the plotting code is using the marching squares algoritm.

```
using Plots
X = LinRange(minimum(x),maximum(x),100)
Y = LinRange(minimum(y),maximum(y),100)
F = Array{Float64}(undef,100,100)
for i ∈ 1:100, j ∈ 1:100
F[i,j] = p[1]*X[i]^2 + p[2]*Y[j]^2 + p[3]*X[i]*Y[j] + p[4]*X[i] + p[5]*Y[j]
end
plot(x,y,seriestype = :scatter, label="Observations", legend=:topleft)
plot!(fx.(ts), fy.(ts), linewidth=3, label="True Ellipse")
contour!(X, Y, F, linewidth=3, levels=[1], color=:green)
plot!([], color=:green, label="Fitted Ellipse")
```
